APPLICATIONS:
• Fans & Blowers
• Pumps
• Compressors
• HVAC Equipment
FEATURES:
• 1 - 75 HP
• 3600, 1800, 1200 RPM
• Open Drip Proof Enclosure (IP22)
• NEMA Premium Efficiency
• CE Mark on Nameplate
• Department of Energy Efficiency Certificate # CC002A
• 36 Month Warranty from Date of Manufacture
• 60 Hz - 230/460V (Usable on 208V). 150 HP and Larger is 460V Only.
• Available in 575V - Note (1)
• 1.15 Service Factor - Continuous
• Class F Insulation with Phenolic Alkyd Resin Varnish
• Class B Temperature Rise
• NEMA Design B Torques
• Oversized Main Conduit Box Rotatable in 90 Degree Increments - F1 Mounted. F2 Available - See "EXTRA/OPTIONS" Below
• Designed for 40oC Ambient Temperature - Note (2)
• Designed for 3300 ft. Elevation - Note (3)
• Bi-Directional Rotation
• Cast Iron Frame and End Brackets
• Rolled Steel Conduit Box
• 1045 Carbon Steel Shaft
• Aluminum Die Cast Squirrel Cage Rotor Construction
• Paint System: Phenolic Rust Proof Base Plus Polyurethane Top Coat
• Paint Color: Light Gray - Munsell N5
• Vacuum De-Gassed Re-Greasable Ball (or Roller) Bearings Frames on 280TS-5009 with Polyrex EM Grease
• Double Shielded Bearings on Frames 140T-280T Pre-Packed with MULTEMP SRL Grease
• Labyrinth Type Metal Flinger on Both Ends for Frames 280TS-5009
• Cast Iron Inner and Outer Bearing Caps for Frames 280TS-5009
• Grounding Terminal Inside Main Box
• Stainless Steel Nameplate
• Inverter Duty Magnet Wire Rated per NEMA MG1 Part 31.4.4.2 - Note (4)
• Speed Ranges: 20:1 VT, 10:1 CT
• 9 Leads - 5 HP and below, 12 Leads - 7.5 HP to 125 Hp, 6 Leads - 150 HP and Larger
• Motors are U.L. Recognized, CSA Approved and CE Marked
• Precautions should be taken to eliminate or reduce shaft currents that may be imposed on the motor by the VFD as stated per NEMA MG1 Part 31.4.4.3. Aegis SGR included.
6205-ZZC3, 25mm x 52mm x 15mm
Available Stock: 9
6205-ZZC3
