FEATURES:
• 1/3 - 10 HP
• 1800 RPM
• Totally Enclosed Fan Cooled (IP44)
• High Torque Design
• 36 Month Warranty from Date of Manufacture
• 1 Phase – 60 H• – 115/230V (3 HP and Larger are 230V Only)
• Capacitor Start, Induction Run – 1/3 to 1.5 HP
• Capacitor Start, Permanent Split Capacitor Run – 2 to 10 HP
• 1.15 Service Factor – Continuous
• Class B Insulation from 1/3 to 3 HP
• Class F Insulation from 5 to 10 HP
• Manual Reset Overload with Outside Rubber Boot
• Class B Temperature Rise
• Bi-Directional Rotation
• Rolled Steel Frame for 1/3 – 1 HP
• Cast Iron Frame for 1.5 – 10 HP
• Rolled Steel Terminal Box
• 1045 Carbon Steel Shaft
• Aluminum Die Cast Squirrel Cage Rotor Construction
• Paint System: Phenolic Rust Proof Base Plus Polyurethane Top Coat
• Paint Color: Green – Munsell 5G 4/ 4
• Double Shielded Bearings Pre-Packed with MULTEMP SRL Grease
• Rubber Flinger on Drive-End
• Grounding Terminal Inside Main Box
• Stainless Steel Nameplate on Frames 143T and Larger
• Motors are UL Recognized and CSA Approved
