Miniature circuit-breaker

Multi 9

Multi 9 C60

C60 UL1077

Distribution

2

15 Aat 77 °F (25 °C)

DC
AC

Thermal-magnetic

Yes conforming to EN/IEC 60947-2

125 V DC
240 V AC
440 V AC
415 V AC

Clip-on

2P

AIR 10 kA at 240 V AC conforming to UL 1077
AIR 10 kA at 125 V DC conforming to UL 1077
Icu 6 kA at 440 V AC conforming to EN/IEC 60947-2
Icu 10 kA at 415 V AC conforming to EN/IEC 60947-2
Icu 20 kA at 240 V AC conforming to EN/IEC 60947-2
Icu 6 kA at 440 V AC conforming to GB 14048.2
Icu 10 kA at 415 V AC conforming to GB 14048.2
Icu 20 kA at 240 V AC conforming to GB 14048.2
AIR 5 kA at 480Y/277 V AC conforming to UL 1077
AIR 10 kA at 240 V AC conforming to CSA C22.2
AIR 5 kA at 480Y/277 V AC conforming to CSA C22.2
AIR 10 kA at 125 V DC conforming to CSA C22.2
Icu 10 kA at 125 V DC conforming to EN/IEC 60947-2
Icu 10 kA at 125 V DC conforming to GB 14048.2

50/60 Hz

C

8.5 x In +/- 20% AC
12 x In +/- 20% DC

3 conforming to EN/IEC 60947-2

500 V AC conforming to EN/IEC 60947-2

6 kV conforming to EN/IEC 60947-2

Yes

Toggle

ON/OFF indication

DIN rail

4

3.19 in (81 mm)

1.42 in (36 mm)

2.87 in (73 mm)

0.49 lb(US) (0.22 kg)

Grey

20000 cycles

10000 cycles

Padlockable

Tunnel type terminal, top or bottom rigid wire(s) 0...0.04 in² (2.5...25 mm²) max (AWG 14...AWG 4)

0.55 in (14 mm) top or bottom

22.12 lbf.in (2.5 N.m) top or bottom

UL 1077
GB 14048.2
EN/IEC 60947-2
CSA C22.2 No 235

CSA
CCC
IEC
UR

IP40 modular enclosure conforming to IEC 60529
IP20 conforming to IEC 60529

3 conforming to EN/IEC 60947-2

IV

2 conforming to IEC 60068-1

95 % 131 °F (55 °C)

6561.68 ft (2000 m)

-22...158 °F (-30...70 °C)

-40...176 °F (-40...80 °C)
