APPLICATIONS:

• Fans & Blowers
• HVAC Equipment
• Pumps
• Fire Pumps (See option below)
• Compressors

FEATURES:

• 200 HP
• 1200 RPM
• Open Drip Proof Enclosure (IP22 Rating)
• NEMA Premium Efficiency
• CE Mark on Nameplate
• Department of Energy Efficiency Certification #CC002A
• 36 Month Warranty from Date of Manufacture
• 60 Hz - 230/ 460V (Usable on 208V). 150 HP and Larger is 460V Only
• Available in 575V - Note (1)
• 1.15 Service Factor – Continuous
• Class F Insulation with Phenolic Alkyd Resin Varnish
• Class B Temperature Rise
• NEMA Design B Torques
• Oversized Main Conduit Box Rotatable in 90 Degree Increments – F1 Mounted. F2 Available – See ExtraS/ Options Below
• Designed for 40°C Ambient Temperature - Note (2)
• Designed for 3300 ft. Elevation - Note (3)
• Bi-Directional Rotation
• Cast Iron Frame and End Brackets
• Rolled Steel Conduit Box
• 1045 Carbon Steel Shaft
• Aluminum Die Cast Squirrel Cage Rotor Construction
• Paint System: Phenolic Rust Proof Base Plus Polyurethane Top Coat
• Paint Color: Blue Gray – Munsell N5
• Vacuum De-Gassed Regreasable Ball (or Roller) Bearings on Frames 280TS - 5009 Using Polyrex EM Grease
• Double Shielded Bearings on Frames 140T-280T Pre-Packed with MULTEMP SRL Grease
• Labyrinth Type Metal Flinger on Both Ends for Frames 280TS - 5009
• Cast Iron Inner and Outer Bearing Caps for Frames 280TS - 5009
• Grounding Terminal Inside Main Box
• Stainless Steel Nameplate
• Inverter Duty Magnet Wire Rated per NEMA MG1, Part 31, 4.4.2 - Note (4)
• Speed Ranges: 20:1 VT, 10:1 CT
• 9 Leads - 5 HP and Below, 12 Leads - 7.5 HP to 125 HP, 6 Leads - 150 HP and Larger
• Motors are UL Recognized, CSA Approved, and CE Marked
