Cross Reference: 21305U, S89-253, 98022S, ODB6002, 04777
| Model_Number: | K041AAT1016013J |
| PRODUCT NAME: | .143 HP - OPEN - 3450 |
| PHASETYPE: | 1_PERM SPLIT CAP |
| MOTOR ENCLOSURE: | OPEN |
| HORSEPOWER: | .143 |
| KILOWATTS: | 0.1 |
| POLES: | 2 |
| NUMBER SPEEDS: | 1 |
| RPM: | 3450 |
| HERTZ: | 60 |
| VOLTS PRIMARY: | 115 |
| VOLTS : | 115 |
| STACK: | 1.625 |
| MOUNTING: | FLANGE |
| MOTOR TYPE: | FHP |
| OPPOSITE END BEARING: | BALL |
| SHAFT END BEARING: | BALL |
| AMBIENT: | 40 |
| ROTATION: | CCW SHAFT END |
| RUNCAPMFD: | 16 |
| RUNCAPVOLTS: | 240 |
| SHIPPING WEIGHT: | 12 |
| BREAKDOWN TORQUE UOM: | OZFT |
| LOCKED ROTOR TORQUE UOM: | OZFT |
| INSULATION CLASS: | F |
| FULL LOAD AMPS PRIMARY: | 1.7 |
